X30-GCC-2 SEAT CARGO

Commercial Commercial Commercial

Description
Overview
Features
Exterior
Interior
Videos
Specifications

Car Overview

Type:

Commercial

Color:

Gold

Features

G01

ESC

X30 LS 9-Seater Deluxe

1499 Ml Displacement

80/75 KW Power

40/45 L Fuel Capacity

LHD RHD Drive

4495×1680×1995 MM Dimension

2945 Wheelbase

1300/2160 Kg weight

195/65R15 Tyre

Daytime Running Light

Radio

Power Window

Reverse Sensor

DLCG14 1.5 L Engine EU V EU VI Emission standard

Display Audio

RKE

X30 LS 2-Seater Cargo Van

M1 Type

2 Seater

Cargo Dimension

Macpherson Front Suspension

Leaf Spring Rear Suspension

Front Discs and Rear Drum Brake

Steel Hub Material

ABS

Front Dual Airbags

Leather Seat

A/C

Location

Loan Calculator

Review (0 Review)

Overall Ratings

0.0

Out Of 5

Comfort

rating 0.0

0.0

Interior Design

rating 0.0

0.0

Performance

rating 0.0

0.0

Speed

rating 0.0

0.0

Leave a review

You need to login in order to post a review.

PDF Brochure

Car Overview

Type:

Commercial

Color:

Gold

Showroom Address

		X30-GCC-2 SEAT CARGO
	SPEC.	COMFORT
SYS.	Parameter Category	CARGO（N1）- 2
General Spec.	Announcement Model	JKC5025XXYA6X2
Driving direction	LHD
Emission standard	EURO V
Length mm	4200
Width mm	1680
Height mm	1930
Wheelbase	2700
Wheelbase front/rear mm	1425/1435
Overhang length front/rear mm	660/840
Inside width of cargo box mm	2215
Interior width mm	1475
Interior height of cargo box mm	1300
Overall mass kg	1160
Rated mass kg	885
Maximum gross mass kg	2135（895/1240）
Number of seats	2
Tire specification	175/70R14
Spare tire specification	175/70R14
Number of closed doors and windows	4
Maximum speed km/h	≤120
Power train	Engine	SWJ15
Displacement ml	1490
Fuel tank	45L
Rated power KW	81
Maximum net power KW	76
Chassis	Tank volume L	╳
Front suspension type	MacPherson
Rear suspension type	Steel plate spring
Number of leaf springs	-/5
Wheel material	Steel wheels + wheel covers
Front Brake Type	Disc
Rear Brake Type	Drum
ESC	Yes
BOS brake priority	Yes
Electric Power Steering (EPS)	Yes
Electronic sys.	Instrument Panel	Korean version
Radio	╳
Floating Players	Yes（USB）
DAB+	Yes
Center 10.25-inch floating screen	╳
Reversing radar	Yes
Reversing camera	╳
Battery	Yes
Front door center console	Yes
Center Door Control	Yes
Tailgate Control	Yes
Key	2 Remot control key
Single Steam Air Conditioning	Yes
Dual Steam Air Conditioning	╳
Heater	Yes
Cigarette lighter/12V power supply	Yes
Rear reading light	Yes
Front headlight	X30L-18 version
Rear fog lamp	Yes
Daytime Running Lights	Yes
Current Tail Lights	Yes
Anti-theft control system	Yes
Tire pressure monitoring (direct)	Yes
Rear window defogger	Yes
Body parts	Front/Rear Bumper	X30L-18 version
Engine grille	Logo: red SRM
Front Door Power Glass Lifter	Yes
Exterior Mirrors	Yes
Front wiper	Yes
Center divider	Sealed divider(with observation window)
Dual airbags	Yes
Front driver’s seat	Comfort with Headrest
Front passenger seat	Comfort with Headrest
Second Row Seats	╳
Third Row Seats	╳
Four-row seat	╳
Main driver’s sun visor	Yes
Passenger sun visor	Yes
Front Seat Belt	3-Point Harness with Retractor
Second row seat belts	╳
Third-row seat belts	╳
Driver Seat Belt Reminder	╳
Accompanying Materials	Warning Triangle Plate/ Accompanying Tools/ Fire Extinguisher/ First Aid Kit/ English/Arabic User’s Manual
	Special Requirement 11	Extreme Heat Environment Adaptation applied
